Fast speed cutting chair seat,3d chair back cutting cnc router machine ,cnc carving cutting wood router machine for chair

Short Description:

UBOCNC multi-functions 3d chair back cutting cnc router machine ：It have double workstations with Vacuum adsorption device,so it can put the materials without turn off machine to improve the efficient.


Product Detail

Product Tags

Feature Of Machine

* Constructed from heavy,all-steel tube frame along with thicken steel gantry that ensure durability.
It also features cast steel gantry supports which greatly dampen vibrations and improves routing quality.
* XY axisfeatures high-precision helical racks and Z axis features ball screw to provide
smooth motion and tight control for precise and quality engraving.
* Y-axis adopt dual-motor drive, powerful and smooth operation.
* The use of breakpoint memory ensures the continuing of processing in case of accidents.
Such as cutter broken, power failure and stuck unforeseen.
* Automatic lubrication system, easy to complete regular maintenance.
*Compatible with any advanced CAM/CAD software,
such as Type3, Artcam,CAXA,Pro-E,UG, Artcut, Mastercam.
* Adopt Off line DSP system, keyboard operation, large screen display, easier to operate
and maintain, more humanized design

Application

1. Woodworking industry:wood crafts,picture frames cutting,handicraft carving wave plates,wooden door production and processing.
2. Advertising industry:advertising materials such as PVC,acrylic,double color plate.
3. Stone working industry:such as natural marble,granite,artificial stone,tombstones,milepost,ceramic tile,glass and other materials
4. Metal industry:carving aluminum,copper,stainless steel and so on.

Main Configuration

Description Parameter
Model UW-1610-2C
Working Area 1600x1000mm
Control system Mach3/DSP Control System
Table Surface T-slot clamping working table
Spindle HQD 6kw Air Cooling Spindle
X, Y Structure Taiwan HIWIN Linear guide rail and helical rack
Z Structure Ball screw and Taiwan HIWIN Linear guide rail
Driver and Motor Servo driver and motor
Rotary axis Can be customized.
Inverter Fuling Inverter
Max. Rapid Travel Rate 45000mm/min
Max. Working Speed 30000mm/min
Spindle Speed 0-24000RPM
Lubrication system Automatic oil pump
Command Language G Code
Computer Interface USB
Collet ER25
X,Y Resolution <0.01mm
Software Compatibility Type3/Artcam Software
Running Environment  Temperature 0 - 45 Centigrade
Relative Humidity 30% - 75%
Optional Italy  air cooling spindleJapan YASKAWA servo motor and driver

Leadshine servo motor and driver

Delta inverter

DSP/WEIHONG system

Vacuum air adsorbing 2 in 1 table

Packing and Service

Packing:
Firstly, packed the cnc router machine with plastic sheet for clearing and damp proofing.
Secondly, then put the cnc router machine in the plywood case for safety and clashing.
Thirdly, transport the plywood case into the container.

Technical support:
1. Our technician can give you remote guide online(Skype or WhatsApp) if any question.
2. English version manual and operation video CD disk
3. Engineer available to service machinery overseas

After sales services:
Normal machine is properly adjusted before dispatch. You will be able to use the machine immediately after received machine.
Besides, you will be able to get free training advice towards our machine in our factory. You will also get free suggestion and consultation, technical support and service by email/skype/tel etc

Samples

afds

FAQ

Q1. How to choose a suitable machine?

You can tell us the working piece material, size, and the request of machine function. We can recommend the most suitable machine according to our experience.

Other kinds of payment we can consider if acceptable for us.

Q2. How long time will need for my machine to delivery?

For standard machines, it would be about 7-10 days. For customized machines according to your specific requirements, it would be about 15-20 working days.

Q3.How can I get the machine ,how to order ?

After we confirm all details ,then You can pay 30% deposit according the Proforma invoice, then we will start to make production. Once the machine is ready , we will send pictures and video to you, and then you can finish the banlance payment. Finally, we will pack machine and arrange delivery for you as soon as possible.

Q4. How to use the machine after receving the machine?

Firstly , when you got machine , you need to contact with us ,our engineer will together with your to deal with it ,secondly ,we send user manuals and

 CD to you before you get the machine ,Thirdly Our professional technician online teach you until you can use it well by yourself.

Q5. About the Payment terms,how to pay money ?

1)T/T, means international bank transfer. 30% deposit, we produce the machine for you. 70% before shipping.
2)L/C at sight
3)D/P at sight
